4-ch DI 4-ch Relay Output, RS485/232 Remote Module

  • April 30, 2015
  • Shenzhen WAYJUN Industrial Automation
4-ch DI 4-ch Relay Output, RS485/232 Remote Module
4-ch DI 4-ch Relay Output, RS485/232 Remote Module

>> Four switch input, four relay output >> Can read input level status via the RS-485/232 interface >> Can set output state via the RS-485/232 interface >> Input/output/power supply: three-isolation >> Isolation between each input,isolation between each output >> Wide power supply range: 8 ~ 32VDC                             >> High reliability, easy programming, easy application >> DIN35 Rail-mounted >> Can programme setting module address,baud rate >> Support Modbus RTU communication protocol >> Dimensions: 120 mm x 70 mm x 43mm Applications: >> level signal measurement, monitoring and control >> RS-485 remote I / O, data acquisition >> Intelligent building control, security engineering applications >> RS-232/485 bus in industrial automation control system >> Industrial signal isolation and long-term transmission                       >> Equipment operation monitoring >> Sensor signal measurement >> Industrial data acquisition and recording >> Medical, industrial product development >> Switching signal acquisition Product Selection: WJ70 -  ‚ñ°           Communication Interface

         485Ôºö output is RS-485 interface            232Ôºö output is RS-232 interface

Sample 1:  part No.: WJ70-232   means output is RS-232 interface Sample 2:  part No.: WJ70-485   means output is RS-485 interface
