- November 20, 2013
- SIEMENS
- Siemens
November 20, 2013 - Siemens introduces three communication modules for Simatic S7-1200 and two matching industrial routers with which remote terminal units (RTUs) can be economically implemented. The communication modules CP 1243-1, CP 1243-1 DNP3, and CP 1243-1 IEC connect the Siemens control via the Telecontrol Basic and Telecontrol Professional telecontrol systems to higher-level systems or a control center. Siemens is also expanding its industrial communication portfolio for telecontrol and teleservice applications with two mobile wireless routers, Scalance M874-2 and Scalance M874-3. The CP 1243-1 module is based on the Telecontrol Basic telecontrol system, which is designed for simple applications and small data volumes. The CP 1243-1 DNP3 and CP 1243-1 IEC communication modules can establish the connections according to the DNP3 and IEC 60870-5-104 telecontrol protocols. They use the comprehensive Telecontrol Professional telecontrol system for demanding monitoring and control tasks. Due to their compact design, the communication modules can be seamlessly installed alongside the Simatic S7-1200 controller. To connect new modules to second-generation mobile wireless networks (GSM, GPRS, and EDGE), Siemens offers the Scalance M874-2 industrial router. The Scalance M874-3 variant establishes links over third-generation networks (UMTS). The user can optionally also connect routers and modules for LTE mobile wireless networks, the Internet, or serial point-to-point links to the new communication modules. Industrial routers or modems are connected to the new communication modules via an Ethernet interface. The new communication modules are configured and parameterized in Step 7 Basic, an engineering tool within the TIA Portal. Users can set parameters for setpoints and alarms quickly and simply in Step 7 Basic. The modular structure comprising the control, communication module, and industrial router and modem enables users to implement economical and space-saving RTUs designed for the specific application. All variants of the new communication module for Simatic S7-1200 transmit measured values, setpoints, and alarms between the RTUs and control center both cyclically and under event control. The devices also notify maintenance personnel by email about previously defined events, for example, exceeded threshold values. The communication modules buffer acquired values with a time stamp, preventing data loss if a communication link fails. As soon as the link is up again, the buffered values are automatically transmitted to the control center in the right time sequence. In addition to use for remote access, CP 1243-1 can also be used for security applications to protect automation cells. The module protects in the an automation cell the connected Simatic S7-1200, for example, by authentication of the network nodes, data encryption within a virtual private network (VPN) and checking data integrity. The Siemens Industry Sector (Erlangen, Germany) is the world's leading supplier of innovative and environmentally friendly automation and drive technology, industrial software and technology-based services. The Sector's comprehensive portfolio covers the entire industrial value chain, from product design, engineering and production to services. Siemens enhances its customers' productivity, efficiency, and flexibility in a wide variety of different industries. With a global workforce of more than 100,000 employees, the Industry Sector comprises the Divisions Industry Automation, Drive Technologies and Customer Services as well as the Business Unit Metals Technologies.
