Optical isolation,Isolated Amplifier can be adjusted
General characteristic:
>>Small size, SIP 12 anti- fire UL94V-0 package >>Can be adjusted >>Three-port (power/input/output) isolation: 3000VDC >>Assistant power supply: 5VDC/12VDC/15VDC/24VDC >>0-5V/0-10V/0-75mV/0-2.5V/2-10V voltage signal or 0-10mA/0-20mA/4-20mA current signal isolation and transfer >>Temperature range: -45~+85 ℃ >>Good anti-jamming capability >> Extremely high linearity (nonlinearity<2%)
Applications：
>>DC current/voltage signal isolation/transmitter/amplifier >> No distortion in long distance signal transmission >> Analog signal data acquisition >> 4-20mA(0-20mA) signal isolation and transfer >> Equipment and sensor signal acquisition >> Signal transmit no-distortion >> Electric power, distant control, isolated safe bar >> 4-20mA sensor analog signal transmission
Selection Guide:
Input Signal |
Power Supply |
Output Signal |
|||
Voltage |
Code |
Power |
Code |
Current |
Code |
0-5V |
V1 |
24VDC |
P1 |
0-20ma |
A3 |
0-10V |
V2 |
12VDC |
P2 |
4-20ma |
A4 |
0-75mV |
V3 |
5VDC |
P3 |
User-defined |
A8 |
0-2.5 |
V4 |
15VDC |
P4 |
||
User-defined |
V8 |
User-defined |
P8 |
||
Samples:
1. Input 0-5V, power supply: 24VDC, Output 4-20mA Part number: IAP-V2-P1-A4 2. Input: 0-3V, power supply: 24VDC, Output: 4-20ma Part Number: IAP-V8-P1-A4(V8:0-3V) 3. Input: 0-75mV, power supply: 24VDC, Output: 4-20ma Part Number: IAP-V3-P1-A4
