January 3, 2019 - Axiomtek introduced the IMB523, the industrial ATX motherboard powered by the LGA1151 socket 8th generation Intel Core i7/i5/i3, Pentium and Celeron processors (codename: Coffee Lake) with the Intel Q370 chipset. The ATX motherboard features four 288-pin DDR4-2666/2400 DIMMs with a memory capacity up to 64GB to meet the needs of high-density computing applications.
The Intel Coffee Lake-based ATX motherboard comes with multiple I/O ports including four RS-232 ports, two RS-232/422/485 ports, two Gigabit LAN ports, six USB 3.1 ports, seven USB 2.0 ports, eight-channel digital I/O, one HD Codec audio, one SMBus, and one PS/2 keyboard/mouse. Moreover, the IMB523 features six SATA-600 ports with software RAID 0/1/5/10. One PCI Express Mini Card slot and one SIM card slot are available for 3G/4G, GPS, Wi-Fi and Bluetooth connections.
To ensure operation across platforms, the industrial motherboard is capable of withstanding an operating temperature range of 0°C to 60°C, and also supports watchdog timer, hardware monitoring functions and Trusted Platform Module 2.0 (TPM 2.0).
