April 2, 2012 – DFI announces CD951 3.5” Single Board Computer with Intel Atom processors. These SBC boards pair an Intel NM10 Express chipset with a range of Intel Atom processors, from the power efficient Intel Atom processor to the enhanced Intel Atom D2700 processor. The dual core processors are built on Intel’s 32-nanometer process technology providing low power consumption and yet higher clock frequencies and faster memory access than their predecessors that are built on 45-nanometer technology.
The CD951 Series features 1 DDR3 800/1066MHz SODIMM that supports up to 2GB system memory, 2 Gigabit LAN controllers, 6 Serial ports, 2 Serial ATA 2.0 ports with speed up to 3Gb/s, 6 USB 2.0 ports, 1 Mini PCIe x1 interface, 1 CompactFlash socket, 8-bit DIO, and a High Definition audio interface. This mobile embedded module board is ideal for applications requiring a stable revision-controlled platform, such as industrial control, security & surveillance, and telecommunications.
For applications requiring a low power solution with passive cooling, the CD951-C2600 uses the Intel Atom N2600 processor offering modest performance with 1.6GHz clock speed and has integrated graphics controller clocked at 400MHz. The CD951-C2800 with Intel Atom N2800 processor operates at 1.86GHz clock speed and 400MHz graphics frequency.
For maximum performance, the CD951-C2700 uses an Intel Atom D2700 processor equipped with a 2.13GHz clock speed and 640MHz graphics frequency. All three processors include integrated graphics with VGA and LVDS interfaces providing dual-independent display capability. In addition, this platform series includes Intel Hyper-Threading Technology that delivers thread-level parallelism and provides a significant increase in performance for multithreaded applications.
Features:
- 3.5” SBC (146mm x 102mm)
- Supports Intel Atom D2700/N2800/N2600 processors
- Intel NM10 Express Chipset
- 1 DDR3 800/1066MHz SODIMM up to 2GB
- VGA and LVDS interfaces supporting dual independent displays
- 2 Intel Gigabit LAN controllers
- 1 RS232/422/485 COM ports
- 5 RS232 COM ports
- 6 USB 2.0 ports
- 2 Serial ATA interfaces (3Gb/s)
- 1 CompactFlash socket
- 8-bit Digital I/O
- 5.1-channel HD audio support
- 1 Mini PCIe x1 slot
About DFI
Established in 1981, DFI is a leading supplier of high-performance computing technology worldwide. With more than 30 years of experience, DFI focuses on innovative design and manufacture of leading-edge board and system level products for embedded applications requiring strict revision control and long life availability. DFI uses the latest technology platforms and manufacturing techniques to produce cost-effective products for use in medical diagnostic & imaging, A/POS, industrial control, kiosk, security & surveillance, digital signage, gaming, and other embedded applications.
As an Associate member of the Intel Embedded Alliance (IEA), DFI works closely with Intel on development of next-generation standards-based building blocks, platforms and solutions for the communications and embedded market segments.
