Encoder differential signal to pulse signal isolator

By: Shenzhen WAYJUN Industrial Automation
17 July, 2014
Encoder differential signal to pulse signal isolator
Encoder differential signal to pulse signal isolator
Differential encoder input signal is directly converted into a pulse signal.

Keywords: Encoder | differential signal | pulse | isolated converter | Signal Conditioner

Features:

>> Differential encoder input signal is directly converted into a pulse signal

>> Support A, B, and Z-phase differential simultaneous conversion

>> 3 inputs, 3 outputs, selectable output pulse amplitude

>> Does not change the original waveform frequency, response speed over 500KHz

>> Power, signal input, signal output isolation 3000VDC three

>> Power supply: 5V, 12V, 15V or 24V DC single power supply

>> Low cost, high small size, ease of use, reliability

>> Standard DIN35 rail mounting

>> Dimensions: 120 mm x 70 mm x 43mm

>> Industrial Temperature Range: - 45 ~ + 85 ℃

Application:

>> Encoder differential signal isolation, acquisition and conversion

>> Differential encoder 24V square wave pulse signal transduction

>> Servo encoder signals to the PLC differential

Pulse signal amplification and shaping

>>Ground interference suppression

>>Motor speed monitoring system

>>Speed measurement and alarm

>>Signals without distortion transmission and transmission

Photo of Shenzhen WAYJUN Industrial Automation

Shenzhen WAYJUN Industrial Automation
Shenzhen WAYJUN Industrial Automation designs A/D and D/A Data Acquisition Module,digital signal DI/DO module, analog signal isolated converter, signal conditioners, 4-20mA current signal splitter, isolated amplifier (RTD/current/voltage/frequency/speed/potentiometer/pulse), Min-power DC DC converters. Our products also carry the CE approval for safety. WAYJUN's products are widely used in the industry power fields of control, electric power, electronic instrument, medical electronic, rail transit, communication, telecom, automation, Medical and Test & Measurement.
