February 21, 2019 - NewTek Sensor Solutions introduced vented versions of its M-375 Miniature LVDT Linear Position Sensors specially designed to provide = accuracy under a combination of high pressure, extreme temperatures, shock and vibration conditions.
Offering a 3/8” diameter, these miniature AC-operated position sensors are ideal for high response dynamic measurement required in hydraulic and material testing systems where space is at a premium. With vented holes in the housing, the M-375 position sensors equalize pressure inside and outside the LVDT linear position sensor to operate in temperature extremes of -65°F to +400°F (-54°C to +204°C) and operating pressures of 30,000 psi . As vented holes expose the coils inside the sensor, any fluid to which the LVDT is exposed must be electrically non-conductive and chemically benign, which is a very common trait among hydraulic fluids and oils.
The NewTek M-375 Series transducers are available in ranges from ± 0.025 inch (± 0.63 mm) to ± 1.0 inch (±25 mm) and operate at a linearity of ±0.15% of Full Range Typical (0.25% max).
