The Local Hand Station is suitable for applications such as large penstocks, where it is difficult to access the actuator due to height, in chamber applications where the actuator is located below the ground and space is limited or for control when the actuator/device may be in a hazardous location.

Also known as an electric cylinder, this direct drive linear motor is 0.75 in. (19.1 mm) in diameter and 2.75 in (69.9 mm) long. Protected inside the motor housing, the linear optical quadrature encoder is directly connected to the shaft.

The 250V STSPIN32F0251 and STSPIN32F0252, and 600V STSPIN32F0601 and STSPIN32F0602 combine three-phase gate drivers and an STM32F0 Arm Cortex-M0 microcontroller for high-voltage Brushless DC (BLDC) motor drives.

The FM drives are equipped with an additional interface board with standard connectors.

The device is suitable for use with both brushed DC and brushless EC motors (BLDC) of up to 120 W and has comprehensive feedback options such as Hall sensors, as well as digital incremental and SSI absolute encoders.

These Yaw-Pitch-Roll stages are designed for the measurement of compound angles or the curvature of an object.

The smart distribution center solutions will include the North American debuts of the EP7402 controller for motor-driven roller (MDR) conveyors, TwinCAT/BSD alternative operating system (OS) for Beckhoff PC-based controllers and C6025 ultra-compact Industrial PC (IPC). The eXtended Transport System (XTS) will also make its MODEX debut at the Beckhoff booth (4026).

The X-410 offers the ability to log a variety of data points such as local and remote I/O, registers, tasks, and voltage. Log entries can be made at preset intervals, scheduled times, triggered by I/O changes or logic events. Users can schedule a daily log file to be sent via email or uploaded via FTP server.

Commander uses a BASIC-like programming language (A-SCRIPT) that allows programmers to compile, read and write standalone programs. The software also provides multi-threading and subroutine support, and can be run in both PC-based and standalone modes.

All sizes of NITRA rodless cylinders have magnetic pistons and are double-acting. The cylinders have front and rear adjustable cushions and tapped end caps for mounting.

The brushless voice coil motors provide 6.3 lbs (28.2 N) of force and peak forces of 20.0 lbs (89.9 N) at a 10% duty cycle for the X and Y axes. The Z axis linear actuator has a continuous force of 21.2 oz (5.9 N) and 67.0 oz (18.6 N) peak force.

WEG SSW05 and SSW07 soft starters are fully digital soft starters with DSP (Digital Signal Processor) controller designed for motor starts and stops. The Gen 2 WEG CFW100 VFD drive is a single-phase input (110/230 VAC), three-phase output variable frequency drive developed for applications ranging from 1/4 to 1hp (0.18 to 0.75 kW).

The linear axis uses a H2W brushless linear motor BLDM-C08 to generate a continuous force of 26 lb [115.5 N] and a peak force of 78 lb [347 N] with a stroke length of 30 in [768 mm].

The VFD-SC series is the same cable as the standard VFD-C series; the addition of the shielded 16AWG signal pair allows the cable to be used with motors and drives requiring brake control or feedback from devices like temperature or position sensors.

The pitch stage has cross roller guides and a range of travel of +/- 10 degrees. The maximum speed is 14 degrees per second with stepper motor driven version and 90 degrees per second with the servo motor driven versions. The 65 mm x 65 mm table has a pattern of threaded holes for fixtures or tooling and has an accuracy of 0.05degrees and repeatability of +/- 0.01degrees.

With a spindle distance of 800 millimeters and spindle speeds to 20,000 rpm, the two-spindle DZ 25 P five axis introduced at EMO 2019 is designed for double-spindle machining of large aluminum structural components with a work area up to 799mm diameter per position.

The gearheads can be equipped with up to four reduction. The GPT family is also particularly suited for accurate positioning applications granted by a very low backlash characteristic.

The three linear voice coil motors in the GVCM-095-089 series features the same housing measuring 3.5 in. (88.9 mm) long by 3.750 in. (95.3 mm) dia. and the same threaded mounting holes for integration into new and existing applications.

The AY110-400-01 rotary stage is equipped with stepper motor and a knob for manual adjustment which can be replaced with an optical encoder for precision position verification. The AY110-400-02 rotary stage is fitted with a DC servo motor and quadrature incremental encoder for closed loop operation.

The Simcenter MAGNET and Simcenter Motorsolve solution calculates the behavior of electromagnetic forces on individual components, providing examination of the structure and materials integrities under multiple operating conditions during any phase of the design process.
