The linear axis uses a H2W brushless linear motor BLDM-C08 to generate a continuous force of 26 lb [115.5 N] and a peak force of 78 lb [347 N] with a stroke length of 30 in [768 mm].

The VFD-SC series is the same cable as the standard VFD-C series; the addition of the shielded 16AWG signal pair allows the cable to be used with motors and drives requiring brake control or feedback from devices like temperature or position sensors.

The pitch stage has cross roller guides and a range of travel of +/- 10 degrees. The maximum speed is 14 degrees per second with stepper motor driven version and 90 degrees per second with the servo motor driven versions. The 65 mm x 65 mm table has a pattern of threaded holes for fixtures or tooling and has an accuracy of 0.05degrees and repeatability of +/- 0.01degrees.

With a spindle distance of 800 millimeters and spindle speeds to 20,000 rpm, the two-spindle DZ 25 P five axis introduced at EMO 2019 is designed for double-spindle machining of large aluminum structural components with a work area up to 799mm diameter per position.

The gearheads can be equipped with up to four reduction. The GPT family is also particularly suited for accurate positioning applications granted by a very low backlash characteristic.

The three linear voice coil motors in the GVCM-095-089 series features the same housing measuring 3.5 in. (88.9 mm) long by 3.750 in. (95.3 mm) dia. and the same threaded mounting holes for integration into new and existing applications.

The AY110-400-01 rotary stage is equipped with stepper motor and a knob for manual adjustment which can be replaced with an optical encoder for precision position verification. The AY110-400-02 rotary stage is fitted with a DC servo motor and quadrature incremental encoder for closed loop operation.

The Simcenter MAGNET and Simcenter Motorsolve solution calculates the behavior of electromagnetic forces on individual components, providing examination of the structure and materials integrities under multiple operating conditions during any phase of the design process.

It is suitable for determining medium to high turbidity values in a large number of applications, especially in the field of the food and beverage industry. The cleaning and sterilisation by means of CIP and SIP procedures are of course possible.

Thanks to its construction with flat ribbon cable, this brushless DC motor is suited for applications with limited space, such as robot grippers, medical pumps or prosthetics.

TOSIBOX Lock for Container is a software-only solution comparable to Tosibox’s previous hardware TOSIBOX Lock products. It enables users to integrate Linux-based IPCs, HMIs, PLCs, controllers or other devices into their TOSIBOX ecosystem and provide secure VPN connectivity to the host device where it is installed, and access to the LAN side devices connected to the host.

The Simatic ET 200SP motor starters are part of an end-to-end distributed peripheral system with outputs of up to 5.5 kilowatts (kW) and cover nearly all motor applications in industry and infrastructure. The failsafe devices ensure full functionality at elevations up to 4,000 meters.

The KinetiMax HPD series is offered in stator-rotors sets. They are available in six frame sizes, with three stack-lengths per size and three windings per stack length. The HPD series also features a large stator bore that allows cabling to pass through for applications such as robotic joints.

The AC stepper drive is powered from 90 to 240VAC and is intended for use with step motors designed to handle a high bus voltage of 340VDC. MTRAC motors are specially designed to work with high bus voltages.

These drives accept a range of input voltages (12-110 VDC, 18-80 VAC) and provide over-voltage and overcurrent protection, motor auto-configuration on power up and Soft-start at power on. Motor output current ranges from 0.3 to 7.2A.

The universally interchangeable design provides flexible installation with C-face and TC-face inputs, perpendicular output and 6 mounting positions. Five gearbox sizes support 56C up to 254/6TC NEMA motor frames and 6 ratios are available from 10:1 to 120:1.

The Allen-Bradley Kinetix 5100 servo drive has multiple control modes available to support a range of high-speed, low-power motion control applications.

The voice coil stage (VCS02-005-BS-01-MXYTh) is a closed loop positioning system that can be used for positioning applications that require a limited rotation theta stage integrated. The stage utilizes a custom low-profile design that utilizes a unique electromagnetic circuit design.

POSITAL’s Hollow Shaft Kit encoders feature an integrated rotation counter that records each revolution the instrument experiences, even if these occur when no external power is available.

AMCI’s SV160E2 Integrated Servo Motor includes an integrated dual port switch with EtherNet/IP, Modbus-TCP, & Profinet connectivity. The SV160E2 incorporates a servo motor, drive, and controller in a single unit.
