The 1 micron resolution HCDS-051-032-013-01-B1-01 Voice Coil Stage features cross roller linear bearings whereas the 30 micron HCDS-051-032-013-01-B1-30 Voice Coil Stage uses linear ball bearings.

POSITAL’s absolute kit encoders are available with multi-turn measurement ranges, which can be useful when a motor is connected to a screw shaft, cable drum or gear reduction system.

The TD family of touch controllers features a differential mutual signal acquisition method that increases the Signal-to-Noise Ratio (SNR).

The U-723 XY stage provides 0.8” travel per axis, with a footprint of 42x42mm (1.6x1.6”). Its profile of 21mm (~0.8”) and design allows for integration into tight spaces. In addition to high resolution (10 nanometer linear encoders) it provides motion up to 200 mm/sec and rapid step/settle performance.

The SCA5618 is available in three lengths and with two different windings. Depending on length, the holding torque of this stepper motor is 0.6 to 2.3 Ncm; it has a resolution of 1.8°.

Eight analog input and combination analog I/O modules are available. 16-channel current input (0-20 mA / 4-20 mA) and 16-channel voltage input (+/- 10VDC, +/- 5VDC, 0-5 VDC, 0-10 VDC) modules provide higher density analog I/O.

The Kinetix 5700 regenerative bus supply regenerates excess energy, putting it back on the facility’s grid or making it available for plantwide use. The Kinetix 5700 large frame drive is designed for machines with large axis counts and higher power requirements. An added large-frame inverter extends the power capability up to 112 kW.

An integrated linear encoder combined with stage calibration provides high accuracy positioning over the full travel of the device. Devices have low pitch, roll, yaw, and runout and a long lifetime.

The service package is tailored for Mitsubishi Electric’s M800 Series, but it also supports CNC products including the M600 Series.

The programmable IDEA Motor integrates a brushless servo motor with an IDEADrive controller in a package designed to reduce design time, wiring needs, and cabinet space.

HMHD-II series Harmonic Gearing Reducer pursues the flat limit —Super Flat Hollow Shaft type— design. Compared with HMHS series, the axial length is only half.

These Partial Extension Rails are Ideally suited for applications requiring smooth motion such as: Material handling, rail systems in trains, aircraft, ships, trucks, and autonomous vehicles, wafer handling, delicate parts transfer, assembly, testing, laser machining and drilling.

The MACH-ProZone is designed for a range of applications that include small to mid-sized roof top and heat pump applications, and small mechanical room applications.

By incorporating two M12 EtherNet/IP connectors instead of just one on each axis, the SWM24IP-3DE Integrated Stepper Motor and TXM24IP-IDG StepSERVO Integrated Motor support more efficient network topologies such as line networks and daisy-chain connections.

Typical applications include machine tools, conveyors, packaging machines, batching machines, food and beverage equipment, pumps and fans.

. The intelligent bearing detects wear and sends a signal to the user if the bearing threatens to fail. Maintenance work can therefore be planned, and operators of agricultural machines, for example, are not surprised during harvest season with an unanticipated breakdown and work stoppage.

This brushless voice coil actuator features a force to size ratio of 5.0 lbs (22.2 N) continuous force and 15.8lb (70.3N) of peak force in either direction, in a housing measuring 2.00 in. (50.8 mm) dia. x 5.00 in. (127.0 mm) long.

Both DPC A and B models feature a choice of eight bore sizes and variable stroke lengths up to four inches. Both models are pre-lubricated with Magnalube-G PTFE grease

The expanded Posi-Lok product line includes nine different models in a range of sizes. Now available are more model and size options to handle different torque requirements and mounting configurations for unique motion control applications.

These Pan (horizontal table)-Tilt (vertical table) Stages are suitable for: Scanning, testing, inspection, assembly, positioning, laser and micro machining, pointing optics and cameras, and other applications.
