The diameter of the rotary table is 300 mm (11.811 in.) and the range of travel is a full 360o, and it is capable of continuous rotation. The table is driven by a 288:1 worm gear and has a resolution of 0.000625o with a 10 micro-step per step stepper motor driver.

The three-phase linear motors deliver up to 3690 N and accelerate at over 200 m/s². The modular design is currently available as actuator version SA (with maintenance-free plain bearing system) and component version SC (for modules).

The JVL EtherCAT module is equipped with two Ethernet connectors and a built-in switch, enabling line, star, tree and ring topology without any extra hardware. The JVL EtherCAT module has several LEDs, enabling technicians and operators to get a status overview.

ACH580 VFDs are integrated with ABB Ability monitoring services – ABB’s cross-industry, digital offering, which provides real-time data about drive status and performance from any location. Monitoring parameters include drives availability, environmental conditions and fault events.

All parameters are software-settable including control-loop gains and system safety functions. With the XL4s, userscan achieve settling times, thermal stability, and sub-micron-level tracking accuracy with features such as full state feed-forward, 192 kHz servo rates, and look-ahead-based velocity control.

JVL’s closed-loop ServoStep technology ultra-high torque enables direct drive without gearing. The motor series also has current control, which lowers power consumption and allows 100% duty cycle without overheating.

The mounting plate, adapter and bus bar system allows UL508A panel builders to assemble in compliance with Type E and Type F stand-alone and group motor control starter applications for a variety of compressor, pump, and fan control scenarios.

The linear profile rails are mounted to a machined aluminum base, which offers support over the entire travel of the table's carriage. The load is mounted to a machined aluminum carriage, which has threaded stainless steel inserts.

This voice coil motor has a force to size ratio of 5.3 lbs (23.5 N) continuous force and 16.7 lb (74.4 N) of peak force at 10% duty cycle with a housing measuring 2.00 in. (50.8 mm) dia. x 1.00 in. (25.4 mm) long.

With continuous force ratings to 200 kN (45,000 lbf) pressing, and speeds to 401 mm/sec (15.8 in/sec), and stroke lengths from 150 mm (6 inches) to 900 mm (36 inches), the FTP Series can be applied across a wide range of pressing applications.

The COMBIVERT S6 is suitable for a range of servo applications, including highly automated, safety-oriented machines. The drives provide motor control in real time, integrated safety functionality and are designed in a book-style format for easier mounting in control cabinets where space can be limited.

The linear travel of the X and Y axes is 100mm x 100mm (3.937 in. x 3.937 in.), and the resolution of each axis is 20 microns(non-micro-step) or 1 micron(20 micro-steps per step motor driver in use), repeatability is 2 microns, and the positional accuracy is 3 microns.

These motors are available in 1200, 1800, & 3600 RPM and have TEFC (Totally Enclosed Fan Cooled) enclosures with cast iron frame and ribbed design for cooling. The motors feature full length, cast iron mounting feet, steel fan cover, and cast iron junction box with rubber gasket and rubber dust cover.

The 352A59 provides results during vibration testing of small structures, primarily because of its 0.03 oz (0.9 gram) mass and sensitivity of 10 mV/g (1.0 mV/m/s2) over a frequency range from 1 to 10 kHz (+/-5%).

The CFW300 features a contactor-style electrical connections (top in / bottom out). The VFD's performance can be scaled to match the application by selecting WEG vector control (VVW) or scalar control (V/Hz).

The sensor, in a functional housing design, will add to EnOcean’s Easyfit portfolio of battery-free Bluetooth switches and support the company’s strategy to provide data for the digitalization of buildings using LED lighting systems as data backbone for intelligent control.

The sensors are available in an M12, M18, or M30 design. Flush installation provided, the nominal switching distances are 2 mm, 5 mm, and 10 mm, depending on the design.

The Commander series are AC motor speed controllers that meet advanced requirements in a range of applications. Both models also include an on-board PLC, for embedded intelligence

The modules feature a metallic plate for functional grounding; 4-pole and 5-pole power connector versions; Ultra-Lock M12 connectors; an IP67 seal; eight digital channels; four motor drive roller channels; diagnostic LEDs; three rotary switches; a two-port Ethernet switch; an Ethernet metallic plate to allow both ODVA and PI grounding strategies; and Ethernet fieldbus connectivity.

The quick connect technology is dubbed the Han ES Press HMC, with the suffix ‘HMC’ standing for High Mating Cycles. The contact inserts are equipped with a pre-tensioned cage clamp which is triggered by an actuator.
