In addition to the standard winding for 24 V with a rated speed of 2760 rpm, customer-specific windings are also possible for series applications. For this motor, the rotor position feedback is provided by hall sensors.

The AQ120 series of linear stages features steel linear ball bearings and steel shafting and are designed for loads of 15 kg (33.1 lbs) for the AQ120-50 to 5 kg (11 lbs) for the AQ120-300. The AQ130 series of linear stages features open steel linear ball bearings and supported hardened steel shafting and is designed for loads to 30 kg (66.1 lbs) for all travel lengths.

PCB’s accelerometer, Model HTJ356B01 is suited for applications that demand ground isolation to reduce electrical noise and ground loops on test articles in higher temperature environments .

LM76's Pegasus Series 1 Linear Bearings feature Silicon Nitride (SiNi) Ceramic Balls in a shell with retainer and end caps all made from 440 Stainless Steel and then ArmorloyTM coated.

The terminal blocks use Push-in connection technology (PT) for nominal cross sections up to 10 AWG, 28 A, and 600 V UL.

QuickStep is a true closed-loop control system that compensates step angle errors during a movement and correct errors within a full step. If load becomes too high speed is lowered and position errors will always stay within two full-steps

Each linear axis uses H2W’s brushless linear motors (BLDM-B04), and each has a total stroke length of 25.67 in [652 mm]; can generate 6.2 lbs [27.8 N] of continuous force and 18.7 lbs [83.3 N] of peak force, or a combined 12.4 lbs [55.6 N] continuous force and 37.4 lbs [166.6 N] of peak force on the bottom axis.

Nine models operate from input ranges of 9 to 18 VDC, 9 to 36 VDC 0r 18 to 36 VDC & provide constant current outputs ranging from 0.10A to 0.90A at corresponding output voltage levels of 14 to 48 VDC.

The U-723 joins PI’s existing portfolio of linear stages. It provides more than 0.8” travel per axis (22x22mm), with a footprint of 42x42mm (1.6x1.6”).

The ILPS-45 linear position sensors are specifically designed for measuring applications requiring rugged devices, whether measuring position of steam turbine valves, mounted in a paper mill head box or calendar roll stand, or outdoors fastened to a building, bridge or structure.

Featuring a -55°C to +125°C temperature range, with available military processing options, the PWR-82335 is ideal for harsh, space constrained defense and aerospace environments.

Used in commercial, industrial, agricultural, law enforcement and harsh environment applications, Elmo’s solutions can stabilize high-resolution cameras, observation systems, communication devices, satellite or ground mobile communication antennas, airplane Sat-Com internet and TV dishes, laser pods, etc.

Used in commercial, industrial, agricultural, law enforcement and harsh environment applications, Elmo’s solutions can stabilize high-resolution cameras, observation systems, communication devices, satellite or ground mobile communication antennas, airplane Sat-Com internet and TV dishes, laser pods, etc.

With the Simosim simulation integrated into the engineering, users can now test their software without connecting any hardware. Program parts are optimized at an early stage of the development phase.

With the M8 D-coded, HARTING now offers a connector that carries power and 100 Mbit Ethernet to the smallest field application.

Through the employment of integrated hardware and sensors, and a proprietary compensation algorithm implemented via Aerotech’s A3200 controller software, ThermoComp works to minimize stage inaccuracy due to thermal effects even over extreme temperature ranges.

Also known as an electric cylinder, this direct drive linear motor is 0.75 in. (19.1 mm) in diameter and 2.75 in (69.9 mm) long.

A solution for applications that require X-Y or X-Z distance, high-speed motion with a load and moment loading capacity, IntelliAxis is ideally configured for pick & place, sorting, loading, assembly and other material handling tasks in industries such as packaging, food and beverage and automotive.

The MX models utilize rows of cylindrical rollers to provide a greater contact area than slides that use steel balls. As a result, bearings deliver load capacities up to 674 kN for dynamic loads and 1,300 kN for static loads.

Netzer’s Rotary Electric Encoders are designed to provide accurate, absolute position with miniature to wide diameter hollow shaft. Available with Analog Sin/Cos, Digital SSi, Digital AqB+I outputs, these rotary encoders feature up to 20 Bit Resolution (with 12 bit A/D) and accuracy to <0.01 .
