The drive offers EMC and connectivity variants for integration and connectivity for machine builders that install hundreds of drives per year. There is a fixed space in the machine for automation and motor control, and the drive needs to meet the space restrictions and connectivity requirements (fieldbus, I/O etc.).

The VCS20-20-03-MC-01-XYZ is a closed loop voice coil driven XYZ positioning stage. It is ideal for three axis positioning applications.

This speed advantage makes the F58 encoders suited to packaging, textile and printing applications—or any other application with fast machines that could be even faster with a position sensing upgrade.

CX0 Series basic area sensors have a sensing distance of up to 6m and a detection height up to 320mm. CX2 Series advanced area sensors also have a sensing distance of up to 6m with detection height of up to 960mm and offer analog outputs and a blanking function.

The MPX3500 has a 15 kg wrist payload capacity and a 25 kg upper arm payload capacity, enabling spray equipment to be mounted directly on the robot arm. It also features a 2,700 mm horizontal reach and ±0.15 mm repeatability.

This interface option is in addition to the previously announced SSI, EtherNet/IP, EtherCat, Powerlink, Profbus DP and Profinet interfaces.

These include the single axis Model 2220 or triaxial Model 2470, featuring aluminum housings and a standard 1 meter integral cable; the single axis Model 2240 or triaxial Model 2480, featuring hermetically sealed titanium housings and an integral connector; and the single axis Model 2276 or triaxial Model 2476, featuring aluminum housings and an integral connector.

The HeiMotion Premium (HMP) brushless AC servo motor is engineered for use in the machine tools, autonomous vehicles, robots, medical diagnostic equipment and similar applications.

The V-731 is equipped with incremental linear encoders for direct position measurement and 3-phase electromagnetic linear motors. Fields of application include micro-assembly, biotechnology, precision laser machining, optics, lens testing, and photonics alignment.

The QF-50 is designed for optical positioning applications requiring precision and throughput coupled with long travels. It offers 400 μm closed loop and 450 μm open loop travel, 0.01% linearity, sub-nanometer resolution, and 4 nm bidirectional repeatability.

The Transport LCU, which is now available for supply, is installed inside the locomotive and serves as the controlling system for remote, wireless control movement of a locomotive through a railyard and is designed as a small space solution.

These controllers can drive up to 500A at 60V, or 300A at 96V respectively. This power capacity makes the controllers a solution for electric vehicles, material handling robots, electric boats or agricultural robots.

The units are available with 3 standard travel ranges from 25 to 100mm in both open and closed-loop configurations. The closed-loop models incorporate a incremental encoder with nanometer resolution.

The Ex9S32 Manual Motor Starters are electro-mechanical devices that combine a number of functions in one unit, including disconnect for motor branch circuit, manual motor control, branch-circuit short circuit protection (magnetic protection), overload protection (thermal protection - Trip class 10) and switching (manual).

The SWM24 integrated steppers combine NEMA 24 step motors with a 6.0 A/phase (peak-of-sine) step motor drive. Power to the drive, located at the rear of the motor, must be supplied by an external DC supply. Applied Motion offers compatible 24 and 48 volt DC power supplies for exactly this purpose.

The LMS-180 is designed for applications where resolution and constant velocity is required, such as in optics inspection, metrology, photonics, interferometry, and semiconductor test equipment.

IONI implements industry standard, torque, velocity and position controls for AC, brushless DC, brushed DC, linear servo motors and stepping motors between 2 W and 700 W power.

SMAC electric grippers incorporate programmable speeds, positions and forces with data feedback. This makes them suitable for a range of positioning, measuring, and inspection applications.

Applications for the PHS series are to be found across industrial, medical and transportation markets, and specific ones include robot joint angle control, motor drive units, 3D printers, rotary angle sensors, HAVC sensors, and shift-by-wire gearshift systems.

PI’s C-663.12 motion controller is designed for 2-phase stepper motors, in open-loop or closed-loop operation commanded by USB or RS-232.
