AutoQuiz is edited by Joel Don, ISA's social media community manager.
This automation industry quiz question comes from the ISA Certified Automation Professional (CAP) certification program . ISA CAP certification provides a non-biased, third-party, objective assessment and confirmation of an automation professional's skills. The CAP exam is focused on direction, definition, design, development/application, deployment, documentation, and support of systems, software, and equipment used in control systems, manufacturing information systems, systems integration, and operational consulting. Click this link for more information about the CAP program.
An application includes a variable frequency drive (VFD) that implements a V/Hz method of torque control while maintaining a fixed V/Hz ratio. The motor has a nameplate rating of 460 volts and 60Hz. If the drive is operating at 30Hz, what percent of rated torque will the motor MOST likely develop?
a) 25% b) 50% c) 100% d) 200% e) none of the above
The volts per hertz ratio (V/Hz) controls the torque of a motor. As long as this ratio is in proportion with the nameplate rating, the motor will develop rated torque. The only answer that represents rated torque is 100% rated torque.
The correct answer is C, 100%.
Reference
: Dave Polka, Motors and Drives: A Practical Technology Guide, Second Edition.
