July 20, 2021 - Research scientists with the Energy Materials Telecommunications Center, National Institute for Scientific Research in Quebec, Canada, have developed a groundbreaking technique 1 to acquire 3D images at over 1000 frames per second with resolution as high as 1180 x 860--far beyond the capabilities of available systems today--by eliminating information redundancy in data acquisition. Certain to open new opportunities for 3D applications, the dual-view band-limited illumination profilometry (BLIP) with temporally interlaced acquisition (TIA) system or simply BLIP-TIA, relies upon the BitFlow Cyton-CXP CoaXPress frame grabber to transmit images from two CMOS cameras to a computer for processing at rates surpassing 12.5 Gb/S.
Existing 3D systems based on the widely used technique of Fringe Projection Profilometry (FPP) have two main limitations. First, each camera captures the full sequence of fringe patterns, therefore imposing redundancy in data acquisition that ultimately clamps the systems’ imaging speeds. Second, the cameras are placed on different sides of a projector. This arrangement often induces a large intensity difference from the directional scattering light and the shadow effect from the occlusion by local surface features, both of which reduce the reconstruction accuracy. To overcome these limitations, the scientists developed BLIP-TIA with a new algorithm for coordinate-based 3D point matching from different views.
Implemented with two cameras from Optronis placed side-by-side and the BitFlow Cyton-CXP frame grabber, it allows each camera to capture half of the sequence of the phase-shifted patterns, reducing the individual camera's data transfer load by 50%, and freeing up capacity to transfer data from more pixels on each camera's sensor or to support higher frame rates. Besides its high-speed data transfer, the Cyton-CXP two-channel frame grabber incorporates the Gen 2.0 x8 PCI Express bus interface on its back-end for high speed access to host memory in multi-camera systems such as the BLIP-TIA. It also allows control commands, triggers and power to be sent to and from cameras over the same coaxial cable to simplify overall design.
To verify high-speed 3D surface profilometry, the researchers used BLIP-TIA in a number of tests including recording non-repeatable 3D dynamics by imaging the process of glass breaking while being struck by a hammer. The growth of cracks and the burst of fragments with different shapes and sizes were clearly shown in the reconstructed 3D images. Besides technical improvements, researchers are now exploring new applications for BLIP-TIA.
For example, it could be integrated into structure illumination microscopy, frequency-resolved multidimensional imaging, dynamic characterization of glass in its interaction with the external forces, recognizing hand gestures for human–computer interaction, in robotics for object tracking and reaction guidance, vibration monitoring in rotating machinery, and for behavior quantification in biological science. (1) "High-speed dual-view band-limited illumination profilometry using temporally interlaced acquisition" Cheng Jiang, Patrick Kilcullen, Yingming Lai, Tsuneyuki Ozaki, and Jinyang Liang (January 2021)
