December 3, 2013 - CONCOA introduced 9940 pipeline regulator designed to exceed heavy heating and cutting pressure and flow requirements. The 9940 series industrial regulator incorporates a high-flow encapsulated soft seat, which has a low cracking pressure. This coupled with a large orifice size enhances the safety and productivity of low-pressure fuel gases. With adequate supply, this enables use of larger heating heads to maximize BTU output. Configured with a 65 mm neoprene diaphragm the 9940 provides stable pressure control.
The encapsulated seat provides a high cycle life due to the integral positive pin stop that prevents the seat from being deformed. Capsule seat technology also surrounds the seat with a 55-micron sintered filter to prevent debris from damaging the seat. The encapsulated seat combines ten to twelve seat components into one assembly, which extends the service life of the regulator. The 9940 offers flow capacity with a Cv of .45.
Outlet pressure ranges offered are 0 -15, 40, and 200-psi. Compliant with CGA pipeline inlet and outlet connections, the 9940 series offers enhanced visibility for fuel, oxygen and inert gases.
The 9940 series weighs just over 3.3 lbs. (1.5 kg).
