Which of the following control valve body styles is MOST likely to develop blockage in a paper pulp slurry service?
a) pinch b) characterized ball c) butterfly d) globe e) none of the above
A globe valve consists of a plug on the end of a stem that moves the plug onto a seat. Because of the body design of this valve, cavities in the body can easily fill with materials and develop blockage. Ball, butterfly, and pinch valve body style have straight-through flow, and they are less likely to develop blockage.
The correct answer is D , globe.
Reference: Bela Liptak, Instrument Engineers' Handbook - Process Control, Volume 2 , CRC Press, and ISA Press.
