May 13, 2019 - The FE060-25-EM is the first servo drive of the FlexPro digital drive family from ADVANCED Motion Controls (AMC). Designed with power density in mind, the micro-sized FE060-25-EM can be integrated into tight spaces.
At 1.5 x 1 x 0.6 inches (38 x 25 x 16 mm) in size, the footprint of the drive is approximately the same as two standard postage stamps. In other words, four of these drives can fit on a standard business card. The FE060-25-EM can supply brushed, brushless, stepper, and linear servo motors with up to 25 amps continuous current and 50 amps peak current.
Features include:
- 1.5 x 1 x 0.6 inches (38 x 25 x 16 mm) in size
- 10-55 VDC supply voltage
- 25A continuous current
- 50A peak current
- EtherCATCommunication
- Incremental encoder and BISS C-mode feedback
- Torque, velocity, and position operating modes
- Configuration and full loop tuning
- IMPACT architecture
A developer version is available for proof-of-concept and testing purposes - part number FD060-25-EM. It comes with an FE060-25-EM soldered to a larger board that is equipped with various connectors for simplified interfacing.
The size of the FE060-25-EM makes it suitable for cobots (collaborative robots), AGVs, portable devices, lab and warehouse automation, military equipment, and any other integrated design.
