March 14, 2019 - The BLUEBOX Panel Reader is an HF/NFC RFID Read & Write Module from the BLUEBOX Line.
The Reader is round with a diameter of 28 mm and a thickness of 9 mm. The integrated antenna transfers data with a maximum speed of 115.200 bits by second.
The Panel Reader is suitable for many applications. It is particularly suited to integration into existing Access Control, Employee Identification, Automation Processes or for NFC Data Transfer.
The Panel Reader is equipped with a 5 Vdc Power Supply. Additionally, the device requires a 2.5 W power supply for operation. The existing USB interface can read and write data in either a Virtual COM Port (VCP) or Keyboard Emulation (HID) mode. This enables integration into all existing Microsoft Windows systems.
The module is equipped with the RFID option HF/NFC: 13.56 MHz. The NFC frequency enables data exchange in near field environments. The HF/NFC frequency supports the ISO 14443A/B and ISO 15693 standards and reads and writes transponders of the MIFARE Classic, Ultralight, Ultralight C, DESFire, Plus, NTAG and NXP transponder types.
A software development kit (SDK) and configuration tool for Windows operating systems is provided as well as an operating system-independent command protocol.
Further adjustments of firmware and hardware are possible on request and project basis.
