March 1, 2009 - Midwest Motion Products released Model No. MMP-TM55-60-24V GP52-195 DC Gear Motor. Accepting any 24 Volt DC source, including battery power, this robust Gear Motor measures just 2.14” in Diameter, by 7.75” long, and has a keyed output shaft of 12mm diameter by 25mm long.
Easy mounting is accomplished with 4 “face mount” M5 threaded holes, equally spaced on a 40mm Dia. B.C. The output of this reversible gearmotor is rated for 196 IN LBS continuous torque, at 7 RPM, and 443 IN LBS Peak.
Despite its compact size, and weight of approximately 4 pounds, it’s an efficient design, requiring just 1.3 Amps at 24Volts DC to generate its Full Load Torque. That translates into long life battery charge, very low noise operation, and lower costs for related drive electronics. Motor windings for 12, 36, 48, 60 & 90 Volts are available. This unique design is rated at an “IP 54” protection level for operation in harsh environments.
Variable Speed can be accomplished with our fully compatible Speed Controls, Model MMP 25A-24V, or MMP 20A-24V-RSP. Samples are available from stock for rapid prototyping needs.
