June 22, 2016 – Nanotec is now offering planetary gears in plastic. The GPLK gears are well suited for applications where the motor must be mobile – for example, in service robotics. With a size of 42 mm and in combination with the BLDC motor DF45, they make a compact drive that weighs 300g and has a torque of 5 Nm.
The GPLEP planetary precision gears are equipped with reinforced output bearings and withstand high radial and axial loads. They are suitable for motor sizes of between 42 and 86 mm. Particularly with small driverless transport systems, this gear type enables simple construction without separate drive wheel bearings.
The GPLEF flange gears for motor sizes of between 56 and 86 mm offer an alternative to cycloidal or shaft gears and have an efficiency rating of 97%. The output flange complies with EN ISO 9409, so swivel arms or rotary tables can be screwed on directly.
