October 3, 2007 - Ashland, MA - The C5100 Series is available in 3 standard DC input voltage ranges from 320-800VDC as well as 3-Phase AC input voltages of 3 x 400VAC (320-460) and 3 x 480VAC (400-530). Single outputs are available in 6 standard ranges from 23-200VDC.
All outputs are adjustable and fully regulated to 0.2% or better (load) and 0.1% (line).All modules in the C5100 series have remote sensing (up to 150VDC output), overvoltage protection, and current limit protection on the output. Efficiencies run up to 95%.
Operating temperatures available include -20°C to +75°C and -40°C to +75°C.The units are packaged in a 3U x 40TE x 538 mm rack module for space savings and incorporate CombiTec I/O connectors. They can be rotated for 5U mounting.
Options available include decoupling diodes for parallel/redundant operation, “ruggedization,” inhibit, Power Fail / DC-OK alarms, system reset, active current sharing, and programming.Applications include railway controls and communications equipment (onboard and trackside), military applications, transportation, telecommunication systems, process control systems, and power stations.Mechanical and electrical modifications to standard modules are readily available upon request. In addition, Schaefer can design and manufacture fully custom solutions.
Series pricing is from $3960.00 at 100 pieces.Significant OEM quantity discounts are available. Delivery is 6-8 Weeks ARO.
