The built-in motor encoder allows closed-loop operation and slip/stall recovery features. An indexed knob provides manual control for operation even without a computer
March 25, 2019 - Zaber’s X-GSR-E Series devices are motorized goniometers with a large diameter of rotation and long travel. The built-in motor encoder allows closed-loop operation and slip/stall recovery features. An indexed knob provides manual control for operation even without a computer. With a low, narrow profile and asymmetric mounting options, these stages excel at angular scanning applications where keeping a clear view of the central target is critical. Curved crossed-roller supports give these devices motion and the roller cam drive provides accuracy.
Features include:
- Integrated, 500 CPR, motor mounted encoder
- Up to 80 °/s speed and up to 60 Nm of torque
- 50 kg centred load capacity
- 150 mm and 225 mm centre of rotation options allow for two axes of motion about a common centre of rotation
