In the post image, which H1 Level Fieldbus topology reflects a "Tree Topology"?
a) Topology A b) Topology B c) Topology C d) Topology D e) none of the above
Tree Topology
concentrates the connection of several field devices to couplers/junction boxes. Tree topology is also known as "Chickenfoot" or "Star" configuration.
a) End-to-End Topology, is used to directly connect two devices. The connection may be entirely located in the field (a transmitter and a valve with no other devices connected) or to connect a field device (a transmitter) to the Host Device.
b) Bus with Spurs Topology, uses a single bus to which devices and spurs are directly connected. Several devices may be connected to each spur. The total spur length is limited according to the number of spurs and the number of devices per spur.
c) Point-to-Point (or Daisy Chain) Topology, has all devices used in the application connected in series. The Fieldbus trunk is routed from one device to the next, being interconnected to the terminals of each Fieldbus device.
The correct answer is C.
Reference
: Foundation Fieldbus, Fourth Edition by Ian Verhappen, CAP, P.E., and Augusto Pereira.
