The Ethernet Direct Layer 3 switches are a combination of technologies in hardware and software engineering to adapt to harsh industrial environments.

This module integrates an antenna capable of a 3-mile range, which allows a pair of modules to communicate in a point-to-point mode or modules can communicate directly to a SignalFire Gateway.

Antaira Technologies’ LMP-2004G-SFP and LMX-2004G-SFP series are industrial-grade equipment that is Ethernet ready to fulfill various markets’ edge-level networking applications in harsh and outdoor environments, such as manufacturing automation, security surveillance, power/utility, water wastewater treatment plants, oil/gas/mining, and transportation.

Your hunt for FDT consultation services stops here! Talk to Utthunga…

New OPC UA plug-in empowers PACTware users with IIoT solutions

Get more from your HART devices with our NEW I/O DTMs

The STRIDE MQTT gateway provides hardware setup to add Modbus RTU/TCP devices to an existing MQTT cloud data collection platform. The MQTT gateway interfaces with up to 32 Modbus devices; wired and Wi-Fi gateway models are available.

Antaira Technologies’ LMP-1600G and LMX-1600G series are industrial-grade equipment that is Ethernet ready to fulfill various markets’ edge-level networking applications in harsh and outdoor environments, such as manufacturing automation, security surveillance, power/utility, water wastewater treatment plants, oil/gas/mining, and transportation.

The module provides CIP Security capabilities to ControlLogix systems. And when combined with the ControlLogix 5580 controller and the Kinetix 5700 drive, it allows a CIP Security zone to be created.

ODVA conformant servo drives, stepper drives, and integrated motors perform their specific positioning, velocity and other motion control tasks while simultaneously exchanging control, I/O and diagnostic data with controllers on the EtherNet/IP network.

By tunneling HART traffic over SignalFire’s proven 900MHz platform, the Link Scout allows maintenance personnel to configure, calibrate and troubleshoot assets equipped with a HART-enabled instrument using DTM software.

The NCS2-MINIPCIE02 is a PTCRB-certified Wi-Fi/3G/4G/LTE NIC module suited for operators and device manufacturers located in regions where PTCRB interoperability/compatibility (cat-3 & cat-6) is a requirement.

The Pocket Portal has an RS-485/power port, input/output port, browser interface, and provides limited control with Modbus RTU write capability (up to 115.2k baud) and 3VDC discrete output logic.

Fiber is most commonly associated with long distance connections. This technology is intended to enhance network with additional bandwidth capacity, and can carry multiple signals concurrently, protecting data from noise and interference without electromagnetic emissions.

This online plant noise surveillance system employs wireless technology and explosion-proof sensors. Even in plants where noise levels change drastically over time, noise mapping can be applied to plan work schedules that will ensure workers do not exceed specified limits for number of work hours in a noisy environment.

Based on the Qualcomm 9205 LTE modem and featuring optional 2G fallback, the modules also provide a future-proof foundation for IoT deployments that span legacy networks, 4G and 5G.

The Kinetix 5700 regenerative bus supply regenerates excess energy, putting it back on the facility’s grid or making it available for plantwide use. The Kinetix 5700 large frame drive is designed for machines with large axis counts and higher power requirements. An added large-frame inverter extends the power capability up to 112 kW.

The gateways enable EtherNet/IP controllers—such as CIP complaint controllers that support Class 1 and Class 3 connections, including PLCs, HMIs, SCADA systems, and OPC servers—to connect to Modbus master controllers.

By incorporating two M12 EtherNet/IP connectors instead of just one on each axis, the SWM24IP-3DE Integrated Stepper Motor and TXM24IP-IDG StepSERVO Integrated Motor support more efficient network topologies such as line networks and daisy-chain connections.

The LNP-0800-60-24 series’ unmanaged switches are designed for expanding the network on the outer edge. Four ports of IEEE 802.3bt 60W 4PPoE power gives users the flexibility to add intelligent devices the network, while still maintaining 4 ports of IEEE 802.3at PoE+ 30W power needed for traditional PoE edge devices.
